109P0424H6D14 PCB Connector Blowers FAN 40X20MM 24VDC LOCK
General Specifications
・ Material ………………………Frame: Plastic (Flammability: UL 94V-0), Impeller: Plastic (Flammability: UL 94V-1)
・ Expected life …………………See the table below. (L10 life: 90% survival rate for continuous operation in free air at 60˚C, rated voltage)
・ Motor protection function ………………… Locked rotor burnout protection, Reverse polarity protection For details, please refer to p. 529.
・ Dielectric strength …………………………… 50/60 Hz, 500 VAC, for 1 minute (between lead wire conductors and frame)
・ Insulation resistance ………………………… 10 MΩ or more with a 500 VDC megger (between lead wire conductors and frame)
・ Sound pressure level (SPL) ……………… At 1 m away from the air inlet
・ Storage temperature ……………………… -30 to +70˚C (Non-condensing)
・ Lead wire ……………………………………… Red Black or Blue Sensor Yellow
・ Mass ……………………………………………… 45 g
| Description: |
| Muti-Port RJ45 side entry Network Jack with shield |
| Number of ports: 1*1 |
| Number of position: 8 |
| Number of contacts: 2,4,6 or 8 |
| |
| Electrical: |
| Rated current: 1.5A |
| Rated voltage: 125VAC |
| Insulation resistance: 500MΩmin |
| Contact resistance: 30MΩmax |
| Withstanding voltage: 1000VAC RMS, 50 or 60Hz 1 Min |
| |
| Materials: |
| Housing: ABS resin (UL94V-0), PBT (UL94V-0), PA66 (UL94V-0), and PA46 (UL94V-0) |
| 2. Contact Wire: Diameter 0.45mm phosphor bronze gold plating over Nickel |
| 3. Shield: 0.20~0.25mm thickness brass with tin plated |
| 4. Gold Plating: Fu",+3u",6u",15u",30u",50u" |
| Product Attributes | Select All |
| Categories | Fans, Thermal Management |
| | DC Fans |
| Manufacturer | Sanyo Denki America Inc. |
| Series | San Ace 40 |
| Part Status | Active |
| Voltage - Rated | 24VDC |
| Size / Dimension | Square - 40mm L x 40mm H |
| Width | 20.00mm |
| Air Flow | 8.2 CFM (0.230m³/min) |
| Static Pressure | 0.280 in H2O (69.7 Pa) |
| Bearing Type | Ball |
| Fan Type | Tubeaxial |
| Features | Locked Rotor Sensor |
| Noise | 35.0 dB(A) |
| Power (Watts) | 1.68W |
| RPM | 8300 RPM |
| Termination | 3 Wire Leads |
| Operating Temperature | -4 ~ 158°F (-20 ~ 70°C) |
| Approvals | CSA, TUV, UL |
| Weight | 0.099 lb (44.91g) |
| Current Rating | 0.070A |
| Voltage Range | 12 ~ 27.6VDC |
